RW-F10.2-B (NA)

10.24 kWh Capacity | 9.2 kWh usable (90% DOD)
6,000+ cycles for long-term reliability
1C charging / 1.25C discharging | 100A continuous (300A peak)
Expandable up to 327 kWh (32-unit max)
IP65-rated enclosure | Operates in -4°F to 131°F (-20°C to 55°C)
Built-in BMS for overcharge/overcurrent protection
Auto-networking modules, no manual coding
LiFePO₄ chemistry | Non-toxic, UL/FCC certified

SKU: RW-F10.2-B Categories: ESS Battery, Low Voltage Series (LV)

Description

The Deye RW-F10.2-B Lithium Iron Phosphate (LiFePO₄) Battery is a premier home battery storage system, also ideal for commercial applications. This photovoltaic battery storage solution elevates energy management with its advanced technology, exceptional durability, and modular scalability. It’s a perfect choice for any home solar system with battery storage.

Feature	Specification
Battery Chemistry	LiFePO₄
Built-in Circuit Breaker	125A 4P, 60Vdc
Capacity (Ah)	200
Scalability	Max. 32 pcs pack (Max. 327kWh) in parallel
Nominal Voltage (V)	51.2
Operating Voltage (V)	43.2 ~ 57.6
Nominal Energy (kWh)	10.24
Usable Energy (kWh)	9.2
Charge/Discharge Current (A) – Recommend	Charge: 100 / Discharge: 100
Charge/Discharge Current (A) – Max.	Charge: 198 / Discharge: 240
Charge/Discharge Current (A) – Peak (2mins, 25°C)	300

Key Features:

Reliable Performance: Equipped with a built-in intelligent Battery Management System (BMS) for reliable operation across extreme temperatures from -4°F to 131°F (-20°C to 55°C). The IP65-rated enclosure further enhances its durability.
High Capacity & Longevity: Nominal energy of 10.24 kWh and a usable energy capacity of 9.2 kWh (90% DOD), this battery delivers consistent energy for years. It supports 6000+ cycles.
Efficient Charge/Discharge: The RW-F10.2-B supports 1C charging and 1.25C discharging, with maximum continuous charge/discharge currents of 100A. It peaks at 300A for high-demand applications.
Flexible Installation: Its flat, modular design allows wall-mounted or floor-standing installation. The battery can be expanded up to 32 units (maximum 327 kWh) for scalability in energy storage projects.
Smart & Convenient: Features auto-networking for battery modules, eliminating the need for DIP switch coding, and supports remote monitoring and upgrades. Seamless integration with Deye inverters ensures a complete energy system.
Eco-Friendly & Safe: Using cobalt-free LiFePO₄ chemistry, the RW-F10.2-B is non-toxic, environmentally friendly, and inherently safe with low-voltage safety connections.
Certified & Backed by Warranty: Certified under UN38.3, FCC, UL1973, and UL9540A, this battery meets rigorous safety standards. 10-year warranty.

Deye RW-F10.2-B is the ideal solution for those seeking efficiency, scalability, and sustainability in their home battery storage system and broader energy storage needs.
