SE-G5.1 Pro-B

  • Safer
    Cobalt Free Lithium lron Phosphate (LFP) Battery: Safety and
    long Lifespan, high efidiency and high power density.
    Inelligent BMS, providing complete protection.
  • Reliable
    Support highdischarge pover. IP20, natural coling, wide
    temperature range: -20C to 55*C.
  • Flexible
    Modular design, easy to expand, Max. 64 units in parallel,
    Max. capacity of 327kWh.
    Suited to residential and commercial apliations for increasing
    the slf-consumptionratio.
  • Convenient
    Battery module auto networking, easy maintenance, support
    remotely monitoring and upgrade, support USB drive upgrade
    the firmware.
  • Eco-Friendly
    Use environmental protection materials, the whole module
    non-toxic, pollution-free.
  • Three Mounting Methods
    19inch Standard design, support rack-mounted, wall-mnounted,
    and floor-mounted, saving installaion space.
SKU: SE-G5.1 Pro-B Category:

Description

Technical Data

Model SE-G5.1 Pro-B
Main Parameter
Battery Chemistry LiFePO4
Capacity (Ah) 100
Scalability Max. 64 pcs pack (327kWh) in parallel (Max. 32 pcs no external setup)
Nominal Voltage (V) 51.2
Operating Voltage(V) 43.2~57.6
Nominal Energy (kWh) 5.12
Usable Energy (kWh) [1] 4.6
Charge/Discharge Current (A) [2] Recommend 50
Max. 100
Peak(2mins,25℃) 150
Other Parameter
Recommend Depth of Discharge 90%
Dimension (W/H/D, mm) 440*133*540
Weight Approximate(kg) 45
Master LED Indicator 5LED(SOC:20%~SOC100%),3LED (working, alarming, protecting)
IP Rating of Enclosure IP20
Operating Temperature Charge: 0~55℃ ( Optional heating: -20℃~55℃ ),Discharge: -20℃~55℃
Storage Temperature 0~35℃
Humidity 5%~95%
Altitude ≤2000m
Cycle Life ≥6000(25℃±2℃,0.5C/0.5C,90%DOD,70%EOL)
Installation Wall-Mounted, Floor-Mounted,Rack-Mounted (19-inch standard cabinet, cabinet depth ≥600mm )
Communication Port CAN2.0, RS485
Warranty Period [3] 10 years
Energy Throughput 16MWh@70%EOL
Certification UN38.3, IEC62619, CE,UK, VDE2510-50, CEI 0-21, FCC, UL1973, UL9540A

[1] DC Usable Energy, test conditions: 90% DOD, 0.5C charge & discharge at 25℃. System usable energy may vary due to system configuration parameters.

[2] The current is affected by temperature and SOC.

[3] Conditions apply, refer to Deye Warranty Letter.
