| Battery Input Data |
| Battery Type |
Lead-acid or Lithium-ion |
| Battery Voltage Range (V) |
40-60 |
| Max. Charging Current (A) |
260 |
280 |
300 |
330 |
350 |
| Max. Discharging Current (A) |
260 |
280 |
300 |
330 |
350 |
| Charging Strategy for Li-ion Battery |
Self-adaptation to BMS |
| Number of Battery Input |
2 |
| PV String Input Data |
| Max. PV Access Power (W) |
28000 |
30000 |
32000 |
36000 |
40000 |
| Max. PV Input Power (W) |
22400 |
24000 |
25600 |
28800 |
32000 |
| Max. PV Input Voltage (V) |
800 |
| Start-up Voltage (V) |
160 |
| MPPT Voltage Range (V) |
160-650 |
| Rated PV Input Voltage (V) |
550 |
| Max. Operating PV Input Current (A) |
36+36 |
| Max. Input Short-Circuit Current (A) |
54+54 |
| No. of MPP Trackers/ No. of Strings MPP Tracker |
2/2+2 |
| AC Input/Output Data |
| Rated AC Input/Output Active Power (W) |
14000 |
15000 |
16000 |
18000 |
20000 |
| Max. AC Input/Output Apparent Power (VA) |
15400 |
16500 |
17600 |
19800 |
22000 |
| Rated AC Input/Output Current (A) |
21.3/20.3 |
22.8/21.8 |
24.3/23.2 |
27.3/26.1 |
30.4/29 |
| Max. AC Input/Output Current (A) |
23.4/22.4 |
25/24 |
26.7/25.6 |
30/28.7 |
33.4/31.9 |
| Max. Continuous AC Passthrough (grid to load) (A) |
70 |
| Peak Power (off-grid) (W) |
2 times of rated power, 10s |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range (V) |
220/380V, 230/400V 0.85Un-1.1Un |
| Rated Input/Output Grid Frequency/Range(Hz) |
50/45-55, 60/55-65 |
| Grid Connection Form |
3L+N+PE |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5% In |
