SUN-7.6/8K-SG02LP1-EU-AM2

Description

Key Features

High Charging and Discharging Capability

The Deye Hybrid Inverter series can handle a maximum charging/discharging current of 250A, facilitating efficient energy transfer and rapid battery charging.

Diesel Generator Compatibility

These inverters are compatible with diesel generators, allowing for seamless integration and energy storage from multiple energy sources, offering greater flexibility and reliability.

Scalability

The series supports up to 16 units in parallel, making it highly scalable for both on-grid and off-grid operations. This makes it a suitable choice for expanding solar energy systems over time.

Battery Versatility

Compatible with both Lead-acid and Lithium-ion batteries, the inverter supports multiple batteries in parallel, providing flexibility in choosing and configuring the energy storage system.

Intelligent Energy Management

With the capability to set up to 6 different time periods for battery charging and discharging, the inverter helps in optimizing energy use according to varying demands and maximizing efficiency.

User-Friendly Interface

Featuring a colorful touch LCD screen, the inverter makes monitoring and controlling the system straightforward, accessible, and intuitive for users.

Robust Durability

Boasting an IP65 protection rating, the Deye Hybrid Inverter is designed to withstand harsh environmental conditions, ensuring longevity and reliable performance in diverse climates.

Technical Specifications

Battery Input Data

• Battery Types: Lead-acid or Lithium-ion
• Voltage Range: 40-60V
• Max Charging/Discharging Current: 250A
• Charging Strategy: Self-adapting to Battery Management System (BMS)
• Number of Battery Inputs: 1

PV String Input Data

• Max PV Input Power: Up to 15600W (depending on the model)
• Max PV Input Voltage: 500V
• Start-up Voltage: 125V
• MPPT Voltage Range: 150-425V
• Rated PV Input Voltage: 370V
• Max Operating PV Input Current: Varies by model
• Max Input Short-Circuit Current: Varies by model

AC Input/Output Data

• Rated AC Input/Output Active Power: Up to 12000W
• Max AC Input/Output Apparent Power: Up to 13200VA
• Rated AC Input/Output Voltage/Range: 220/230V
• Rated Input/Output Grid Frequency/Range: 50/45-55Hz, 60/55-65Hz
• Grid Connection Form: L+N+PE
• Max Continuous AC Passthrough (grid to load): 2 times of rated power for 10s
• Power Factor Adjustment Range: 0.8 leading to 0.8 lagging

Efficiency and Protection

• Max Efficiency: 97.6%
• Euro Efficiency: 96.5%
• MPPT Efficiency: >99%
• Total Current Harmonic Distortion (THDi): <3% (of nominal power)
• DC Injection Current: <0.5% In
• Equipment Protection: Comprehensive protection features include DC polarity reverse connection protection, AC output overcurrent protection, overvoltage protection, short circuit protection, thermal protection, and more.

Environmental and Physical Data

• Operating Temperature Range: -40 to +60 ℃ (Derating above 45 ℃)
• Permissible Ambient Humidity: 0-100%
• Permissible Altitude: 2000m
• Noise Level: <45 dB
• Ingress Protection (IP) Rating: IP65
• Cooling Method: Intelligent air cooling
• Dimensions: 420×670×233 mm (excluding connectors and brackets)
• Weight: 35.6 kg
• Warranty: 5 Years/10 Years, depending on the final installation site of the inverter (for detailed information refer to the warranty policy)

Communication and Monitoring

• Monitor Modes: GPRS/WIFI/Bluetooth/4G/LAN (optional)
• Communication Interfaces: RS485/RS232/CAN

Compliance

• Grid Regulation Standards: VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0-21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150
• Safety/EMC Standards: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

The Deye Single Phase Hybrid Inverter series provides an innovative solution for managing solar energy efficiently and reliably, making it an excellent choice for various solar installation needs.
