BOS-GL & BOS-GH

  • 19″ rack-mountable LiFePO₄ modules with optional USB/Wi-Fi upgrades
  • Remote monitoring & firmware updates (Sol-Ark compatible)
  • Scalable: parallel multiple modules for 40–61 kWh capacity
  • Wide operating range: –20 °C to 55 °C, IP20 enclosure
  • Comprehensive protection (over-charge/discharge, over-current, temperature)
  • Auto balance, low self-discharge (6 months), no memory effect
SKU: BOS-GL & BOS-GH Category:

Description

Introducing the Deye SUMMER BOS Series, a premier small-scale Commercial & Industrial Energy Storage Solution. This series, featuring the BOS-GL and BOS-GH models, offers a blend of convenience, reliability, and intelligent design for your energy needs.

Parameter BOS-GL60 BOS-GH40 BOS-GH60
Cell Chemistry LiFePO₄
Module Energy (kWh) 5.12
Nominal Voltage (V) 51.2
Module Capacity (Ah) 100
Modules in Series (optional) 6 8 12
System Voltage (V) 307.2 409.6 614.4
System Energy (kWh) 61.44 40.96 61.44
Usable Energy (kWh) 55.29 36.86 55.29
Charge/Discharge Current Recommend: 100 A
Nominal: 100 A
Peak 2 min: 125 A
Recommend:50 A
Nominal: 100 A
Peak 2 min: 125 A
Recommend: 50 A
Nominal: 100 A
Peak 2 min: 125 A
Recommended DoD 90%
Cycle Life ≥ 6,000 cycles to 70 % EOL (0.5C/0.5C, 25 ± 2 °C)
Warranty 10 years
Dimensions (W×D×H mm) 530 × 667 × 2,187 530 × 667 × 1,629 530 × 667 × 2,187
Weight (kg) 75+45 × 12+20=635kg 53+45 × 8+20=433kg 75+45 × 12+20=635kg
Communication Port CAN 2.0 / RS485
Ingress Protection IP20
Installation Rack Mounting
Certifications UL1973, UL9540A, UN38.3, UL9540

Key Features Across the Series

Convenient by Design:

  • A sleek, 19-inch embedded design that fits seamlessly into your setup.
  • Flexibility with optional USB and Wi-Fi upgrade capabilities.
  • Remote monitoring and upgrades are made easy, with compatibility for Sol-Ark inverters.
  • Scale your energy storage by connecting multiple battery modules in parallel.

Safe and Reliable Performance:

  • Built with LFP (LiFePO4) battery technology, ensuring safety, a long lifespan, and high-energy density.
  • The module is non-toxic, non-polluting, and eco-friendly.
  • Operates reliably in a wide working temperature range from -20°C to 55°C.

Intelligent Functions:

  • Comprehensive protection against over-discharge, over-charge, over-current, and temperature fluctuations.
  • Automatically manages charge and discharge cycles while balancing current and voltage for optimal performance.
  • Features low self-discharge, allowing it to be shelved for up to 6 months without charging.
  • No memory effect, with excellent performance in shallow charge and discharge scenarios.
