SE-G10.2 (AS, AF, LATAM)

  • High Capacity: 200 Ah nominal capacity with 10.24 kWh energy storage
  • Safe and Reliable: Cobalt-free lithium iron phosphate (LFP) chemistry
  • Wide Operating Range: Functions effectively in temperatures from -20°C to 55°C
  • Modular Design: Expandable up to 64 units in parallel for scalable energy solutions
  • User-Friendly: Automatic networking, remote monitoring, and easy firmware upgrades
  • Eco-Friendly: Constructed with non-toxic, pollution-free materials
  • Versatile Mounting Options: Supports rack, wall, or stacked installations for efficient space usage
  • Robust Communication: Equipped with CAN 2.0 and RS485 ports for seamless connectivity
  • Long Cycle Life: Over 6000 cycles at optimal conditions, ensuring durability and reliability
SKU: SE-G10.2 (AS, AF, LATAM)Category:Low Voltage Series (LV)
Contact Us

Description

Introducing the SE-G10.2 battery, powered by Lithium Iron Phosphate (LiFePO4) chemistry, designed to deliver outstanding performance and reliability.

Specification Details
Model SE – G10.2
Battery Chemistry Lithium Iron Phosphate (LiFePO4)
Nominal Capacity 200 Ah
Nominal Voltage 51.2 V
Operating Voltage 44.8 V – 57.6 V
Nominal Energy 10.24 kWh
Cell Configuration 2P16S
Max. Charge Current 100 A continuous, 200 A peak (10 sec)
Max. Discharge Current 100 A continuous, 200 A peak (10 sec)
Recommended Depth of Discharge 80% DoD
Dimensions 710 mm (W) × 540 mm (D) × 133 mm (H)
Weight Approx. 85 kg
Cycle Life ≥6000 cycles (at 25℃ with 0.2C discharge and 80% DoD)
Warranty Period 5 years
Communication Port CAN2.0, RS485
IP Rating IP20
Operating Temperature Charging: 0℃ to 55℃, Discharge: -20℃ to 55℃
Storage Temperature 0℃ to 35℃
Relative Humidity Up to 95%
Altitude ≤2000 m

Key Features:

  • High-Performance Specs: Boasts a nominal capacity of 200 Ah, nominal voltage of 51.2 V, and nominal energy of 10.24 kWh. It supports a max continuous charge/discharge current of 100 A (200 A peak for 10 sec) and an operating voltage range of 44.8 V – 57.6 V.
  • Exceptional Durability: Offers a cycle life of ≥6000 cycles (at 25℃ with 0.2C discharge and 80% DoD) and comes with a 5-year warranty. Even at end – of – life (EOL), it retains 70% capacity.
  • Versatile Operation: Charging temperature ranges from 0℃ to 55℃, while discharge is possible from -20℃ to 55℃. It’s suitable for both residential and commercial use, with easy expandability – up to 64 units can be paralleled for 327kWh/655kWh total capacity.
  • User-Friendly & Safe: Enables easy operation and maintenance with auto battery module networking (no DIP switches), remote monitoring/ firmware upgrade, external power supply activation to prevent suspension, and over-discharge direct recharge. The built-in circuit breaker, intelligent BMS, and eco-friendly, non-toxic materials ensure safety.
